Used 2007 MAZAK Nexus Quick Turn 200ii | CNC 2 Axis Turning Centers
Have one to sell?
ConditionUsed
1 available
Mazak Nexus Quick Turn 200ii with Mazak Matrix Control 8" Chuck, Parts Catcher, Quick Tool Setter, Chip Conveyor
Mazak Nexus Quick Turn 200ii
with Mazak Matrix Control
Main Specifications
Bar Capacity: 2.56"
Chuck Size: 8"
Spindle Speed: 5,000 RPM
Spindle Motor: 15 HP
X Axis Travel: 7.67"
Z Axis Travel: 22.04"
Rapid Rate Z Axis: 1,299 IPM
Turret Tools: 12 Station
Rapid Rate X Axis: 1,181 IPM
Max Turning Dia: 13.78"
Max Turning Length: 21.3"
Max Swing: 20.67"
Tailstock Body Travel: 21.75"
Tailstock Center: MT#5
Spindle Nose: A2-6
Weight: 12,000 LBS
Options:
Mazak Matrix
Chip Conveyor
Tool Presetter
Tailstock
Parts Catcher
