Description

2018 Muratec "Murata" MW-180G CNC Twin Spindle Turning Center w/Overhead Gantry Loader with Fanuc 31iTB CNC Control and All Options with Rare Muratec MW-200G Diameter (14) Pallet Stocker Feeder Table Left Side of Machine and MW-120G Standard Diameter (14) Pallet Stocker Feeder Table
Right Side on Machine Cell with All Installed Chucks & Tool Holders & Options Included.

MAIN SPECIFICATIONS:
Swing:................................................. 11.6"
Distance Between Spindles:.............. 17.4"
Chuck Size:.........................................(2) Kitagawa 8" 3-Jaw
No Turret Stations:............................ (2) 10 Stations
Max Workpiece Size:........................ 7.87" With Loader
Max Turning Length :........................ 4.7" With Loader
Max Spindle Speed:.......................... 3500 RPM
Spindle Drive Motor:......................... 20 Hp.
X-Axis Travels:................................... 7.4"
Z-Axis Travels:.................................. 6.7"

Spindle Nose A2-6
Approx Machine Dimensions 92" x 86"
Approx. Weight 16,000 Lbs.

Machine Ran Only Light Near Net Cutting and is in 10-10 Condition.

EQUIPPED WITH
Fanuc 31iTB CNC Controls
(2) Pallet Stocker Feeder Table
Gantry Loading/Unloading System
LNS Turbo Rear Discharge Chip Conveyor
Light Near Net Cutting Application Only!

Spindle Cutting Hours Left Side 13,118
Spindle Cutting Hours Right Side 13,185

I thank you on your review and look forward to reviewing

This Rare Top Condition Machine and Options.
