Used EUROTECH TA-20-YS-640 | 5-Axis or More CNC Lathes

2021 EUROTECH TA-20-YS-640/Fanuc 32iTB with 15 " touch screen and new iHMI

Description
G codes type A in Fanuc control
Machine Manuals in pdf format available for download in
N-55 15 position turret
Standard hydraulic cylinder in main spindle (TA20 Autoblok VNK 150-67)
Air blow over main spindle
Removable tool pre-setter
Side exit chip conveyor for Z=640 bed (standard type)
Machine status indicator light
Tool life management function
Tool load monitoring function
High pressure coolant pump (6 bar)
High pressure coolant pumps (6 bar + 15 bar)
Coolant filter 250μm with scraper type cleaning system
Pneumatic, automatic, programmable parts catcher with conveyor
Bar feed interface - Unimag
Parts ejector for sub spindle (Pneumatic type) with adjustable stroke of 100mm
Coolant through sub spindle

Optional tool holders
TTL/10400/02 Axial driven toolholder ER32 with internal coolant 70bar (12000rpm)
TTL/10400/05 Radial driven toolholder ER32 (12000rpm)
Wrench for ER16 ring nut (330.12.0634)
Wrench for ER32 ring nut (330.12.0637)
Max diameter of swinging over bed: 760 mm
Max diameter of swinging over slides: 600 mm
Max turning diameter: 460 mm
Distance between center of spindles: 625 mm
X- axis travel: 310 mm
Z-axis travel: 640 mm
Y-axis travel: +70 -50
B-axis travel: 640 mm
Max speed: 3500 rpm
Bearing outside diameter: 200 mm
Bearing inside diameter: 130 mm
Spindle nose inside diameter: 91 mm
Draw tube bore: 82 mm
Chuck diameter: 255 / 315 mm
Chuck bore: 82 mm
Turning torque: 1020 Nm max
Number of positions on turret: 14 Section on tools: 25x25 mm
Max speed sub spindle: 4500 rpm
Machine dimensions: 2542 x 1760 x 2120 mm

LNS QUICKLOAD SERVO 3+ BARFEEDER – 4FT
TRANSFORMER 51KVA

Machine Confirmed Hours:
Power on 1190 Hrs.
Runtime Only 273 Hrs.
Cutting 153 Hrs.

Full tooling package would be for sale with the machine!.
60 Pc on Live & Static Tool Holders More details in Process!.

Sincerely,
Mark Murphy

Murphy Machinery
Office: 262-534-4124
Mobile: 414-520-0843
Email: markmurphy@murphymachinery.com
WebSite: www.murphymachinery.com
